Category: Pompa Pedrollo

Specification Product : Model   (230V/50 Hz) 4PD/2 Rated Power P2 1.5 kW 2 HP Axial load (N) 2500 Revs (1/min) 2810 Starting Current/ Rated Current 3.2 Efficiency (ɳ) 66% Power factor (cos φ) 0.93 Rated Torque (Nm) 5.1 Starting Torque/ Rated Torque 0.8 Capacitor (Vc-450V) µF 50 h (mm) 467 Weight 13.6 kg Voltage 10.6 A

Specification Product : Model   (230V/50 Hz) 4PD/3 Rated Power P2 2.2 kW 3 HP Axial load (N) 2500 Revs (1/min) 2820 Starting Current/ Rated Current 4.1 Efficiency (ɳ) 68% Power factor (cos φ) 0.97 Rated Torque (Nm) 7.51 Starting Torque/ Rated Torque 0.77 h (mm) 565 Weight 18.2 kg Voltage 14.6 A

Specification Product ; Model   (400V/50 Hz) 4PD/0.50 Rated Power P2 0.37 kW 0.50 HP Axial load (N) 1500 Revs (1/min) 2808 Starting Current/ Rated Current 4 Efficiency (ɳ) 62% Power factor (cos φ) 0.76 Rated Torque (Nm) 1.3 Starting Torque/ Rated Torque 2.8 h (mm) 304 Weight 7.2 kg Voltage   230 V 2.1 A 400 V 1.2 A 240 V 2.1 A 415 V 1.2 A

Specification Product : Model   (400V/50 Hz) 4PD/0.75 Rated Power P2 0.55 kW 0.75 HP Axial load (N) 1500 Revs (1/min) 2790 Starting Current/ Rated Current 3 Efficiency (ɳ) 65% Power factor (cos φ) 0.85 Rated Torque (Nm) 2 Starting Torque/ Rated Torque 1.8 h (mm) 304 Weight 7.2 kg Voltage   230 V 2.8 A 400 V 1.6 A 240 V 2.9 A 415 V 1.7 A

Specification Product : Model   (400V/50 Hz) 4PD/1 Rated Power P2 0.75 kW 1 HP Axial load (N) 1500 Revs (1/min) 2790 Starting Current/ Rated Current 3.7 Efficiency (ɳ) 69% Power factor (cos φ) 0.75 Rated Torque (Nm) 2.6 Starting Torque/ Rated Torque 2.7 h (mm) 329 Weight 8.5 kg Voltage   230 V 3.6 A 400 V 2.1 A 240 V 3.8 A 415 V 2.2 A

Specification Product : Model   (400V/50 Hz) 4PD/1.5 Rated Power P2 1.1 kW 1.5 HP Axial load (N) 1500 Revs (1/min) 2780 Starting Current/ Rated Current 3.5 Efficiency (ɳ) 70% Power factor (cos φ) 0.79 Rated Torque (Nm) 3.9 Starting Torque/ Rated Torque 2.4 h (mm) 354 Weight 10.4 kg Voltage   230 V 5.0 A 400 V 2.9 A 240 V 5.2 A 415 V 3.0 A

Specification Product : Model   (400V/50 Hz) 4PD/2 Rated Power P2 1.5 kW 2 HP Axial load (N) 2500 Revs (1/min) 2825 Starting Current/ Rated Current 4.4 Efficiency (ɳ) 69% Power factor (cos φ) 0.76 Rated Torque (Nm) 5.07 Starting Torque/ Rated Torque 2.9 h (mm) 428 Weight 11.1 kg Voltage   230 V 7.1 A 400 V 4.1 A 240 V 7.4 A 415 V 4.3 A

Specification Product : Model   (400V/50 Hz) 4PD/3 Rated Power P2 2.2 kW 3 HP Axial load (N) 2500 Revs (1/min) 2820 Starting Current/ Rated Current 4.4 Efficiency (ɳ) 74% Power factor (cos φ) 0.76 Rated Torque (Nm) 7.45 Starting Torque/ Rated Torque 2.5 h (mm) 467 Weight 14.0 kg Voltage   230 V 9.9 A 400 V 5.7 A 240 V 10.4 A 415 V 6.0 A

Specification Product : Model   (400V/50 Hz) 4PD/3 Rated Power P2 3 kW 4 HP Axial load (N) 2500 Revs (1/min) 2810 Starting Current/ Rated Current 4.7 Efficiency (ɳ) 74% Power factor (cos φ) 0.78 Rated Torque (Nm) 10.18 Starting Torque/ Rated Torque 2.7 h (mm) 522 Weight 15.6 kg Voltage   230 V 13.0 A 400 V 7.5 A 240 V 13.7 A 415 V 7.9 A

Specification Product : Model   (400V/50 Hz) 4PD/5.5 Rated Power P2 4 kW 5.5 HP Axial load (N) 2500 Revs (1/min) 2820 Starting Current/ Rated Current 5.1 Efficiency (ɳ) 78% Power factor (cos φ) 0.77 Rated Torque (Nm) 13.53 Starting Torque/ Rated Torque 3.1 h (mm) 587 Weight 18.8 kg Voltage   230 V 17.0 A 400 V 9.8 A 240 V 17.8 A 415 V 10.3A
